Compellent SCv2000/Chassis 12 x 3.5"/7x2TB/Bezel/Dual 12Gb SAS/Redundant 580W/3Yr PS NBD

Popis produktu:

Compellent SCv2000/Chassis 12 x 3.5"/7x2TB/Bezel/Dual 12Gb SAS/Redundant 580W/3Yr PS NBD

Dell Storage SCv2000 array
2U, 12 (twelve) 3.5” HDDs
Expands up to 168 HDDs
1GB iSCSI, 10GB iSCSI, 12GB SAS or 16GB FC
8GB cache per controller
4 Core processors (Intel)
Dynamic Capacity
Virtual Ports
Dynamic Controllers
Enterprise Manager

Storage drives installed* Yes
Installed storage drive type* HDD
Number of storage drives installed* 7
Total installed storage capacity* 14000 GB
Supported storage drive types* HDD, SSD
Number of storage drives supported* 12
Storage drive interface* Serial Attached SCSI
Storage drive capacity 2000 GB
Storage drive size 3.5"
RAID levels 5, 6, 10
Hot-swap drive bays Yes

Ports & interfaces
Host interface* SAS
Host ports 2
USB 3.0 (3.1 Gen 1) Type-A ports quantity 1
Remote management port RJ-45 (Gigabit)

Design
Chassis type * Rack (2U)
Colour of product Black, Grey
LED indicators Yes

Power
Power supply unit (PSU) capacity 580 W
Redundant power supply (RPS) support Yes
AC input voltage 100-240 V
AC input frequency 50/60 Hz

Weight & dimensions
Width 482 mm
Depth 576 mm
Height 87.9 mm
Weight 28.9 kg

Operational conditions
Operating temperature (T-T) 5 - 57°C
Operating relative humidity (H-H) 10 - 80%
Storage temperature (T-T) -40 - 65°C
Storage relative humidity (H-H) 5 - 95%
Operating altitude 0 - 3048 m
Non-operating altitude -300 - 12192 m

Technické špecifikácie sa môžu meniť bez predošlého upozornenia. Obsah aktuálneho balenia sa môže líšiť v závislosti od dátumu predaja. Obrázky majú len informatívny charakter.
