Compellent SCv2000/Chassis 12 x 3.5"/7x4TB/Bezel/Dual 10Gb iSCSI/Redundant 580W/3Yr PS NBD

Popis produktu:

Compellent SCv2000/Chassis 12 x 3.5"/7x4TB/Bezel/Dual 10Gb iSCSI/Redundant 580W/3Yr PS NBD

7x4TB NL SAS (7.2k rpm) 3.5"
Dell Storage SCv2000 array
2U, 12 (twelve) 3.5” HDDs
Expands up to 168 HDDs
1GB iSCSI, 10GB iSCSI, 12GB SAS or 16GB FC
8GB cache per controller
4 Core processors (Intel)
Dynamic Capacity
Virtual Ports
Dynamic Controllers
Enterprise Manager

Storage
Storage drives installed* Yes
Installed storage drive type* HDD
Number of storage drives installed* 7
Total installed storage capacity* 28000 GB
Supported storage drive types* HDD, SSD
Number of storage drives supported* 12
Storage drive interface* Serial Attached SCSI
Storage drive capacity 4000 GB
Storage drive size 3.5"
RAID levels 5, 6, 10
Hot-swap drive bays Yes

Ports & interfaces
Host interface* iSCSI
Host ports 2
USB 3.0 (3.1 Gen 1) Type-A ports quantity 1
Remote management port RJ-45 (Gigabit)

Design
Chassis type* Rack (2U)
Design
Color of product Black, Grey
LED indicators Yes

Energy Management
Power supply unit (PSU) capacity 580 W
Redundant power supply (RPS) support Yes
AC input voltage 100-240 V
AC input frequency 50/60 Hz

Weight & Dimensions
Width 19" (482 mm)
Depth 22.7" (576 mm)
Height 3.46" (87,9 mm)
Weight 63.7 lbs (28,9 kg)

Operational Conditions
Operating temperature range (T-T) 5 - 57°C
Operating relative humidity range 10 - 80%
Storage temperature range (T-T) -40 - 65°C
Storage relative humidity range 5 - 95%
Operating altitude 0 - 120000.1" (0 - 3048 m)
Non-operating altitude -11811 - 480000.3" (-300 - 12192 m)
