MSI B450M MORTAR/Socket AM4/DDR4/USB3.1/DP/HDMI/mATX

Popis produktu:

PROCESSOR
Support AMD® Ryzen™ 1st and 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics Processors for Socket AM4

See supported processors

CHIPSET
AMD® B450 Chipset

MEMORY
4 x DDR4 memory slots, support up to 64GB
Supports 1866/ 2133/ 2400/ 2667Mhz (by JEDEC)
Supports 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466 MHz (by A-XMP OC MODE)
Dual channel memory architecture
Supports non-ECC UDIMM memory
Supports ECC UDIMM memory (non-ECC mode)
Please refer to www.msi.com for more information on compatible memory
See supported memory

SLOTS
1 x PCIe 3.0 x16 slot (PCI_E1)
Supports x16 speed with AMD® Ryzen™ 1st and 2nd Generation processors
Supports x8 speed with AMD® Ryzen™ with Radeon Vega Graphics processors
1 x PCIe 2.0 x16 slot (PCI_E4, supports x4 mode)1
2 x PCIe 2.0 x1 slots2
PCI_E4 slot will be unavailable when an M.2 SSD is installed in the M2_2 slot.PCI_E2 slot will be unavailable when an expansion card is installed in the PCI_E3 slot.
ONBOARD GRAPHICS
1 x DisplayPort, support a maximum resolution of 4096x2304 @60Hz, 2560x1600 @60Hz, 3840x2160 @60Hz, 1920x1200 @60Hz1,2
1 x HDMI™ 1.4 port, supports a maximum resolution of 4096x2160 @30Hz, 2560x1600 @60Hz1,2
Only support when using AMD® Ryzen™ with Radeon Vega Graphics ProcessorsMaximum shared memory of 2048 MB
MULTI-GPU
Supports 2-Way AMD® CrossFire™ Technology
STORAGE
AMD® B450 Chipset
4 x SATA 6Gb/s ports1
1x M.2 slot (M2_2, Key M)1
Supports PCIe 2.0 x4 2242/ 2260 /2280 storage devices
AMD® CPU
1x M.2 slot (M2_1, Key M)*1
Supports PCIe 3.0 x4 and SATA 6Gb/s 2242/ 2260 /2280 storage devices
PCI_E4 slot will be unavailable when an M.2 SSD is installed in the M2_2 slot.
RAID
AMD® B450 Chipset
Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices
Supports RAID 0 and RAID 1 for M.2 NVMe RAID
USB
AMD® B450 Chipset
1 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) Type-C port on the back panel
1 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) Type-A port on the back panel
6 x USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A ports on the back panel, 2 ports available through the internal USB 3.1 Gen1 connectors)
6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB 2.0 connectors)
AUDIO
Realtek® ALC892 Codec
7.1-Channel High Definition Audio
Supports S/PDIF output
LAN
1 x Realtek® RTL8111H-CG Gigabit LAN controller
INTERNAL CONNECTORS
1 x 24-pin ATX 12V power connector
1 x 8-pin ATX 12V power connector
4 x SATA 6Gb/s connectors
2 x USB 2.0 connectors (support additional 4 USB 2.0 ports)
1 x USB 3.1 Gen1 connector (support additional 2 USB 3.1 Gen1 ports)
1 x 4-pin CPU fan connector
3 x 4-pin system fan connectors
2 x 5050 RGB LED strip 12V connectors
1 x TPM module connector
1 x Front panel audio connector
2 x System panel connectors
1 x Chassis Intrusion connector
1 x Clear CMOS jumper
1 x Serial Port connector
1 x Parallel Port connector
BACK PANEL PORTS
BIOS FLASHBACK+ Button
PS/2 Combo Port
DisplayPort
LAN Port
USB 3.1 Gen2 Type A
HD Audio Connectors
USB 2.0 Port
HDMI Port
USB 3.1 Gen1
USB 3.1 Gen2 Type C
Optical S/PDIF OUT
MSI B450M MORTAR back panel ports
DIMENSIONS
9.6 in. x 9.6 in. (24.4 cm x 24.4 cm)
Micro-ATX Form Factor
MOUNTING
8 mounting holes

OPERATING SYSTEM
Support for Windows® 10 64-bit
Support for Windows® 7 64-bit
* To support Windows® 7 64-bit, you must install an AMD Pinnacle Ridge & Summit Ridge CPU.

Stránky o produkte:

https://www.msi.com/Motherboard/B450M-MORTAR
