Sapphire NITRO+ AMD Radeon RX 6700 XT 12GB/192-bit GDDR6 HDMI 3xDP

Popis produktu:

NITRO+ AMD Radeon™ RX 6700 XT
GPU: Boost Clock: Up to 2622 MHz
Memory: 12GB/192 bit DDR6. 16 Gbps Effective
Stream Processors: 2560
RDNA™ 2 Architecture
Ray Accelerator: 40


GPU
AMD Radeon™ RX 6700 XT Graphics Card
7nm GPU
AMD RDNA™ 2 Architecture
Engine Clock
Boost Clock: Up to 2622 MHz
Game Clock: Up to 2548 MHz
Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary.

Stream Processors
2560
Infinity Cache
96MB
Ray Accelerators
40
Memory Size/Bus
12GB GDDR6
Memory Clock
16 Gbps Effective
Displays
Maximum 4 Displays
Resolution
HDMI™: 7680×4320
DisplayPort1.4: 7680×4320
Interface
PCI-Express 4.0

Output
1x HDMI
3x DisplayPort


BIOS Support
Dual UEFI
Game Index
4K

Sapphire Features
Dual BIOS
TriXX Software BIOS Switch
Premium Digital Power Design
Fuse Protection
Tri-X Cooling Technology
Intelligent Fan Control
Precision Fan Control
Backplate with ARGB
Two-Ball Bearing Fans
Hybrid Fan Blade
Wave Fin Design
V Shape Fin Design for GPU Cooling
Integrated Cooling Module
TriXX Supported
Fan Check
Fan Quick Connect
TriXX Boost
NITRO Glow
External RGB LED MB Synchronization
AMD Features
AMD RDNA™ 2 Gaming Architecture
DirectX® 12 Ultimate
Hardware Raytracing
Smart Access Memory
Infinity Cache
7nm GPU
PCI® Express 4.0 Support
AMD FreeSync™ Technology
DisplayPort™ 1.4 with DSC
HDMI™ 2.1 VRR
Video Streaming up to 8K
Radeon™ VR Ready Premium
AMD FidelityFX
Radeon™ Image Sharpening
Radeon™ Anti-Lag
Radeon™ Software
Game Driver Optimizations
Cooling
3 Fans

Form Factor
2.5 slot, ATX
Dimension: 310.05(L)X 130.75(W)X 51.4 (H)mm
Power Consumption
260W (Board Power)
OS
Linux®, Windows® 7*, Windows® 10, and Windows 8.1. 64-bit  operating system required

*Does not support all features including but not limited to Hardware Raytracing

System Requirement
Minimum 650 Watt Power Supply
1 x 8-pin + 1 x 6-pin Power Connector.
PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard.
Minimum 8GB of system memory. 16GB recommended.

Stránky o produkte:

https://www.sapphiretech.com/en/consumer/nitro-radeon-rx-6700-xt-12g-gddr6

Technické špecifikácie sa môžu meniť bez predošlého upozornenia. Obsah aktuálneho balenia sa môže líšiť v závislosti od dátumu predaja. Obrázky majú len informatívny charakter.
